Fibre Patch Lead Om3 Sc-St 2m Aqua Duplex Multimode

$6.67
In stock
SKU:
F2313-020
UPC:
9317057534466
Condition:
New
Availability:
Ships From Warehouse

Product Description

This OM3 Duplex Multimode Fibre Optic Cable is ideal for connecting 10GBase-SR, 10GBase-LRM, SFP+ and QSFP+ transceivers for 10 gigabit network connections. This cable provides backward compatibility with existing 50/125 equipment and the performance headroom required to support LED and VCSEL laser light sources, and 10 gigabit ethernet applications.

Product Features

  • Designed for 10Gbase-SR and LRM applications
  • Backward compatible with existing 50/125 equipment
  • Available in SC, ST and LC connectors
  • Available in lengths up to 10m
  • Optical Multimode 3 (OM3) fibre supporting 2000 MHz.km EMB at 850 nm
  • 10 Gigabit transfers up to 300 metres using 850 nm VCSEL source
  • LC Connector Dimensions: 10.75mm Height x 12.5mm Width x 50mm Depth (with installed duplex clip)
  • Maximum Connector Loss: 0.50 dB
  • Typical Connector Loss: 0.30 dB
  • Typical Return Loss: -25 dB
  • Buffer Material: PVC
  • Buffer OD: 900 µm
  • Jacket Material: PVC (OFNR riser-rated)
  • Jacket OD: 1.8 mm
  • Installation Tensile Load: 100 N (445 lbs)
  • Long-Term Tensile Load: 50 N (222 lbs)
  • Maximum Tensile Load: 100 N/cm
  • Installation (Loaded) Minimum Bend Radius: 5.0cm (1.97in)
  • Long-Term (Unloaded) Minimum Bend Radius: 3.0cm (1.2in)
  • Crush Resistance: 750 N/cm
  • Impact Resistance: 1,000 cycles
  • Flex Resistance: 5,000 cycles
  • Attenuation at 1300 nm: 1.0 dB/km
  • Attenuation at 850 nm: 3.5 dB/km
  • Operating Temperature: -20°C to +70°C
  • Please Note: Attenuation testing performed in accordance with EIA/TIA-455-171A

Other Details

CAT #:
F2313-020
Length:
2.0m
Colour:
Aqua
Cable Type:
Fibre
